| 37m Purse Seiner |
 |
VESSEL TYPE : Purse Seiner Fishing Vessel
BUILD : 1984 Ireland
CLASSIFICATION : INSB
DIMENSIONS
LOA : 37,5 m
BREADTH : 7,99 m
DEPTH : 6,5 m
DRAUGHT : 5,3 m
CAPACITIES : 434 m3 in 6 RSW tanks
MACHINERY
Main Engine : ABC 6MDZC
Auxiliary Engine 1: Caterpillar 3406 / 250 KVA
Auxiliary Engine 2 : Caterpillar 3306 /115 KVA
Auxiliary Engine 3 : Baudouin DF 6 / 40 KVA
PROPULSION
Main gearbox / propeller : Norgear 6FGC335 / Pitch Propeller
Bow Thruster : 180 HP (Hydraulic type)
Stern Thruster : 350 HP (Hydraulic type)
DECK EQUIPMENT
Winches : 2 x Seljeseth SSW 1800, 18 t
Capstan : Ørekarl
Cranes : Triplex KN 10
Net Hauler : Triplex NK 3000
Fish pump : Karm, 14”
Net Winch : Triplex type 603
Ring Needle : Triplex
Fish discharge pump : MMC
RSW system : 420 kw
FISH FINDING ELECTRONICS
Low frequency Sonar : Simrad SX 90
High frequency Sonar : Furuno CH 71
Echo sounder : 2 x echo sounders
NAVIGATION EQUIPMENT
Radar : Furuno FR2110
Map plotter : Olex
GPS : 2 x Furuno type GP150/GP500
RADIO EQUIPMENT
SSB MF/HF radio : Furuno type FS 1562-15 MF/HF
DSC receiver : Furuno DCS 60
VHF : 2 x Sailor RT 144 C
DSC VHF : Furuno FS 1562/RX
Sat phone : Skanti, Type ICUH 7701
Navtex : NAV 5 GMDSS
Inmarsat : Inmarsat C, Sailor H2095 C
ACCOMMODATIONS : 9 crew members |
| Year: | 1984 |
| Length: | 37.5m |
| Location: | Poland |
| Status: | Available |
| Contact: | TAG Marine | | Telephone: | +27766160242 |
|
| |
More information and photos |
|
| 38m Purse Seiner |
 |
Registered length: 38.70 metres
Length overall: 42.80 metres
Length between perpendiculars: 35.10 metres
Breadth: 8.60 metres
Depth amidships: 6.45 metres to the top of the shelter deck
GRT: 471.00
NRT: 141.00
Lightship: 539.98 metric tonnes, including solid ballast of ± 66.6
tonnes
Built: 1983, Iyideniz Kavak, Tersaunesi, Istanbul, Turkey,
1991 – whaleback fitted
Crew: 14 men
Speed: 10 knots |
| Year: | 1983 |
| Length: | 38' 7" |
| Location: | Cape Town Western Cape South Africa |
| Status: | Available |
| Contact: | TAG Marine | | Telephone: | +27766160242 |
|
| |
More information and photos |
|
| Stern Freezer Trawler |
 |
VESSEL PARTICULARS
Registered Length - 31.33m
Beam 7.90m
GRT - 378t
Year Built - 1988
Class IRS
WHEELHOUSE
The wheelhouse contains the following items of navigation and fish finding equipment
1 x Furuno GPS model GP70 MK2
1 x Furuno Navtex receiver Nav5
1 x Capsat satellite telephone
1 x Furuno SSB radiotelephone FS 1502
1 x Furuno GPS model GP 30
1 x Furuno GPS Navigator, GP-70 MK 2
1 x Furuno colour LCD echo sounder Type FCV 1200L
1 x Furuno radar FR-7062
1 x Inmarsat - C
1 x Navitron autopilot
2 x emergency VHF handheld radios
1 x Scanmar SGM 15 monitor
1 x SART Rescuer transponder
1 x EPIRB
2 x Sailor VHF radios
1 x Chronometer
1 x Barometer
1 x Rudder indicator
1 x Gyro compass
1 x Navigation light panel 220/24 volt
1 x Buoyer public address system serving all compartments
1 x Blue finger Azurtrac-SC VMS
Machinery control and alarm panel
Hydraulic steering via joystick and wheel
FACTORY DECK
1 x stocker Pond
1 x Fish Washing Machine
1 x Fish Heading Machine
FISH HOLD
One fish hold which is totally insulated and refrigerated and the deck and bulkheads are fitted with cargo battens.
ENGINE ROOM
Buhrmeister & Wain six cylinder turbocharged and after-cooled two-stroke marine diesel engine which develops 746 kW at 500 RPM. Final drive is via a Liaan reduction gearbox which is fitted with a clutch and the pitch control for the controllable pitch propeller.
2 x Guascor 8 cylinder marine diesel auxiliary engines which develop 240 kW each and drive Indar alternators
2 x ABC three stage air compressors
1 x Alfa Laval oil separator MAB 104-B
1 x bench grinder
1 x Transarc welding machine
1 x HP washing machine |
| Year: | 1998 |
| Length: | 35.33m |
| Location: | Namibia |
| Status: | Sold |
| Contact: | TAG Marine | | Telephone: | +27766160242 |
|
| |
